Mr-Glass Windows & Doors - Residential Products
Series MG-350(PW)
Impact Resistant Fixed Picture Window
- Meets HVHZ. LMI Rated
- DP= +/-65 PSF
- Sizes: 48” x 84” / 36” x 108” / 24” x 168”
- Slim structure to maximize glass view and day light opening
- Extrusions are 2-3/16” deep to have the minimal impact on interior finish during retrofit
- Shapes and Figures available, colonials for design freedom
- Meets ANSI Z97.1 (Human fall/impact protection)
- Machine glazed with silicone GE 2000/DS795
- Laminated Heat Strengthened Glass with 0.09 thick PVB as interlayer
- Clear, tinted, or reflective glass. Low-e glass for enhanced Solar Heat Gain Coefficient while allowing maximal transparency and visual light
transmittance - Silicone glazing gasket and stainless steel screws
- Powder coat finish. Standard and custom colors. Meeting AAMA 2604 as standard finish (5 years warranty) with possibility to upgrade to AAMA 2605 (10 years warranty)
- Aluminum 6063T6 structure
